BLANKOM IGS-800

Entwickelt für lokale IPTV Verteilnetze auf LANs und für OTT Betreiber. BLANKOM IGS-800 kann bis zu 128 Fernsehkanäle aus 8 Satelliten-Transpondern oder DVB-C oder DVB-T Kanälen in IPTV-Signale – zu einem unschlagbaren Preis – umsetzen.

  • 8 Tuner Eingänge DVB-S/S2/C/T
  • 90 Mbps max. Bitrate für jeden Eingang
  • nur FTA
  • IP (128 SPTS) über UDP und RTP / RTSP Ausgang
  • Unterstützt maximal 128 PID-Mapping pro Eingang.
  • Bedienung über NMS Software
  • Firmware Update über das Internet.
  • Professionelle Qualität, sehr gutes Preis-Leistungsverhältnis.

BLANKOM IGS-800 DVB/IP gateway has 128 SPTS IP capacity. Supports up to 128 PID mapping per input.

It has 8 DVB-S/S2/C/T tuners built inside, thus can receive 128 different programs from 8 different transponders/channels.

Features

BLANKOM IGS-800 is a DVB/IP Gateway, which has eight DVB-S/S2 tuners (DVB-C, DVB-T/T2 optional) and de-multiplexing functions in one case to convert RF signals into TS output.

It is in a 1U case which supports 8 tuner inputs.

To meet customers various requirements, IGS-800 is designed to de-mux programs from any RF input.
It is capable to generate 128x SPTS streams in UDP, RTP/RTSP.

Application

Converting the content of 8x fta satellite transponders into IP, for generating SPTS IPTV content.

Technical Specifications

Function DVB / IP Gateway with 8x RF input, IP port.

INPUT

  • RF 8x RF DVB-S/S2, DVB-C, DVB-T, F type
  • 90 Mbps max. bitrate per each input

TUNER

  • DVB-S
    Input frequency: 950-2150 MHz
    Symbol rate: 2-45 Msps
    Signal strength: -65 -25 dBm
    Constellation: ½, 2/3, ¾, 5/6, 7/8 QPSK
  • DVB-S2
    Input frequency: 950-2150 MHz
    Symbol rate: QPSK 1-45 Msps, 8PSK 2-30 Msps
    Code rate: ½, 3/5, 2/3, ¾, 4/5, 5/6, 8/9, 9/10
    Constellation: QPSK, 8PSK
  • DVB-C
    J.83A (DVB-C), J.83B, J.83C 47 – 860 MHz
    Constellation: 16/32/64/128/256 QAM
  • DVB-T
    44 – 1002 MHz
    Bandwidth: 6, 7, 8 MHz

OUTPUT

  • IP 128x SPTS over UDP, RTP/RTSP. 2x 1000M Base-T Ethernet interface (unicast/multicast) and 2x SFP module interface
  • 800 Mbps max. output bitrate
  • Control over network management (WEB NMS), English menu

GENERAL

  • Dimensions 483mm × 440mm × 44mm, 19” 1U, 5 kg
  • Power AC 110V±10%,50/60Hz or AC 220V±10%, 50/60Hz
  • Temperature 0~40℃ (operation)
